3003 Aluminum Honeycomb Core

Structural Core Material with Highest Strength to Weight Ratio

Additional information

Weight 3 kg
Dimensions 200 × 100 × 3 cm
Foil thickness

0.04mm, 0.05mm, 0.06mm, 0.07mm, 0.08mm

Cell size

3.2mm, 4.8mm, 5.2mm, 6mm, 6.48mm, 6.9mm, 8.7mm, 10.4mm, 13mm, 15mm, 17.3mm, 19mm, 21mm, 26mm, 30mm

Details about 3003 Aluminum Honeycomb Core

Aluminum honeycomb core as a new product, it has been widely applied in various fields. our company’s products market nationwide and exported to all over the world.
there are two types of aluminum alloy,  3003 aluminum honeycomb core and 5052 aluminum honeycomb core.here is for 3003 aluminum honeycomb core details.


3003 Aluminum  honeycomb core applications:
  • Lighting industry: exhibition. the traffic light, etc.
  • Decoration materials: aluminum honeycomb panel wall plywood, aluminum honeycomb composite ceiling, partition, fire doors, marble panels, etc.
  • Transportation industry: aluminum honeycomb composite of the train, train doors, partition, aluminum honeycomb composite ship trim panels, etc.
  • Furniture industry: all kinds of furniture of honeycomb composite with moisture-proof, fire prevention function.
  • other applications for which elevated physical and mechanical properties are not required.
3003 Aluminum honeycomb is available in four forms: unexpanded blocks, unexpanded slices, untrimmed expanded sheets, and cut to size expanded sheets. It is also available with or without cell perforations to facilitate cell venting for certain applications.
